| จำนวน： | |
|---|---|
SMLSCO
TP316/ลิตร, TP304/ลิตร
ASTM A351 CF8M
ISO, พีอีดี
13.7-114.3mm, DN8-DN100, 1/4-4
ถุงผ้าหรือตามลูกค้า
FOB/CFR/CIF ฯลฯ
T/T, L/C หรือเป็นการเจรจาต่อรอง
| DN | ขนาด | ด้าย | D | d | L | J | T | H | กิโลกรัม |
| DN8 | 1/4 ' | BSPT | 17 | 11.3 | 19.2 | 6 | 1.85 | 11 | 0.023 |
| DN10 | 3/8 ' | BSPT | 22 | 14.5 | 21.5 | 6 | 1.75 | 12 | 0.033 |
| DN15 | 1/2 ' | BSPT | 26 | 18.5 | 25.8 | 7 | 2.5 | 14 | 0.063 |
| DN20 | 3/4 ' | BSPT | 32 | 26.5 | 30.5 | 7 | 1.5 | 13 | 0.086 |
| DN25 | 1 ' | BSPT | 39 | 33.5 | 35.5 | 8 | 1.5 | 13 | 0.129 |
| DN32 | 1-1/4 ' | BSPT | 48.5 | 42 | 41 | 9 | 2 | 15 | 0.216 |
| DN40 | 1-1/2 ' | BSPT | 55 | 48.5 | 46 | 9 | 2 | 16 | 0.285 |
| DN50 | 2 ' | BSPT | 66.5 | 59.5 | 58.25 | 13.5 | 2.25 | 23 | 0.514 |
| DN65 | 2-1/2 ' | BSPT | 84.5 | 76.5 | 66.5 | 12 | 2.5 | 20.5 | 0.79 |
| DN80 | 3 ' | BSPT | 97 | 88 | 77 | 14.5 | 3 | 23 | 1.134 |
| DN100 | 4 ' | BSPT | 124 | 114.5 | 91 | 16 | 2.5 | 26.5 | 1.874 |
 |  |
| DN | ขนาด | ด้าย | D | d | L | J | T | H | กิโลกรัม |
| DN8 | 1/4 ' | BSPT | 17 | 11.3 | 19.2 | 6 | 1.85 | 11 | 0.023 |
| DN10 | 3/8 ' | BSPT | 22 | 14.5 | 21.5 | 6 | 1.75 | 12 | 0.033 |
| DN15 | 1/2 ' | BSPT | 26 | 18.5 | 25.8 | 7 | 2.5 | 14 | 0.063 |
| DN20 | 3/4 ' | BSPT | 32 | 26.5 | 30.5 | 7 | 1.5 | 13 | 0.086 |
| DN25 | 1 ' | BSPT | 39 | 33.5 | 35.5 | 8 | 1.5 | 13 | 0.129 |
| DN32 | 1-1/4 ' | BSPT | 48.5 | 42 | 41 | 9 | 2 | 15 | 0.216 |
| DN40 | 1-1/2 ' | BSPT | 55 | 48.5 | 46 | 9 | 2 | 16 | 0.285 |
| DN50 | 2 ' | BSPT | 66.5 | 59.5 | 58.25 | 13.5 | 2.25 | 23 | 0.514 |
| DN65 | 2-1/2 ' | BSPT | 84.5 | 76.5 | 66.5 | 12 | 2.5 | 20.5 | 0.79 |
| DN80 | 3 ' | BSPT | 97 | 88 | 77 | 14.5 | 3 | 23 | 1.134 |
| DN100 | 4 ' | BSPT | 124 | 114.5 | 91 | 16 | 2.5 | 26.5 | 1.874 |
| |
